型号:
NX-65P
1.RMS Power Handling RMS功率处理：150W
2.Peak Power Handling峰值功率处理：500W
3.Components(Drivers)组件(驱动程序)：LF 1x6.5"/ 1.6" (35mm) Voice coil
HF 1x1.4"/ 35mm voice coil
4.Nominal lmpedance正常阻抗：8 ohms
5.Frequency Response频率响应(±3 dB)：65Hz-20KHz
6.Sensitivity(1W @ 1M)灵敏度(1W @ 1M)：95dB
7.Maximum SPL 最大声压：103dB
8.Nominal Dispersion覆盖角度：H100°xV10°
9.Input Connectors 输入连接器：2 x Speakon NL4MP
10.Output Connectors输出连接器：2x Combo XLR, 3pin
11.Other Function 其他功能：TWO CHANNLS 2*400W Sub ultra low frequency 40Hz-250H with independent
Volume adiustment;Phase shift;CLASS AB
12.Cabinet material柜体材料：18mm plywood
13.Surface Finished 表面处理：spray painting+ metal grille
14.N.W(1pc)净重：24.7kg
15.G.W(with flight Case)毛重：26.9kg
16.Dimensions(W*D*H) 尺寸(宽x深x高)：450*500*400mm
17.Package(flight Case) 包装尺寸：530*560*460mm
型号：NXS-12A
1.RMS Power Handling RMS功率处理：350W
2.Peak Power Handling峰值功率处理：1250W
3.Components(Drivers)组件(驱动程序)：LF 1x12"/ 1pcs 3" (100mm) Voice coil
4.Nominal lmpedance正常阻抗：8 ohms
5.Frequency Response频率响应(±3 dB)：35Hz-500Hz
6.Sensitivity(1W @ 1M)灵敏度(1W @ 1M)：102dB
7.Maximum SPL 最大声压：109dB
8.Nominal Dispersion覆盖角度：H100°xV10°
9.Input Connectors 输入连接器：2x Combo XLR, 3pin
10.Output Connectors输出连接器：2x Combo XLR, 3pin
11.Other Function 其他功能：TWO CHANNLS 2*400W Sub ultra low frequency 40Hz-250H with independent
Volume adiustment;Phase shift;CLASS AB
12.Cabinet material柜体材料：18mm plywood
13.Surface Finished 表面处理：spray painting+ metal grille
14.N.W(1pc)净重：24.7kg
15.G.W(with flight Case)毛重：26.9kg
16.Dimensions(W*D*H) 尺寸(宽x深x高)：450*500*400mm
17.Package(flight Case) 包装尺寸：530*560*460mm
